Agrifence Offset Ring Insulator Cranked 10 Pack – Electric Fence Insulators

Agrifence Cranked Offset Ring Insulator – 21cm, Pack of 10

Same 21cm offset, different geometry. The arm on this one is cranked rather than straight, which lifts the ring above the line of the shaft and lets the rope or wire sit higher than the point where the insulator is screwed in.

That matters when the post you have is not at the height you want. On a low stock fence, or where the sound timber is below the height a horse actually leans, the crank buys you the extra rise without a second row of posts. Agrifence's stated aim is the same as the straight version — keeping animals off permanent posts — reached from a fixing point that would otherwise be too low.

Performance & Benefits

• Cranked arm positions the rope or wire higher than the fixing point.
• 21cm offset holds the conductor clear of the post.
• Ring fitting for rope and wire.
• Lets a live line be run at horse height off a low or awkward post.
• Ten per pack.
• Protects permanent fence posts from rubbing and chewing damage.

Suitable For

• Low stock fences that need a live line at horse height.
• Posts where the sound timber is below the working height of the fence.
• Rope and wire systems on permanent post-and-rail.
• Mixed-height boundaries where the offsets need to line up but the posts do not.
• Not the version to buy where the post height is already right — the straight-shafted Agrifence Offset Ring Insulator 21cm is simpler to line up and takes the Speediso drill bit.

How to Use

• Work out the height you want the line at, then how far above the fixing point that is.
• Screw the shaft into sound timber with the crank rising into the field.
• Keep every insulator on the run cranked the same way, or the line will wander in height.
• Thread the rope or wire through the ring rather than knotting it on.
• Check the arms after stock have been in; a cranked arm is a longer lever and takes more of a knock.

Specification

• Agrifence product code H4815. Barcode 5052150001555.
• Pack of 10.
• Offset length 21cm, with a cranked arm.
• For wire and rope conductors.
• Agrifence publish no rise dimension for the crank, no material and no load rating, so none of those figures are given here.
